POWER

Engine 4-stroke Single
Displacement 144 cm³
Bore x Stroke 58.0 x 54.4 mm
Compression Ratio 9.5:1
Valve System SOHC, 2 valves
Fuel System Keihin PB20
Ignition Digital DC-CDI
Starting Electric
Cooling Air-cooled
Lubrication Forced lubrication, wet sump
Transmission 5-speed, return
Primary Reduction Ratio 2.880 (72/25)
Gear Ratio: 1st 2.667 (40/15)
Gear Ratio: 2nd 1.895 (36/19)
Gear Ratio: 3rd 1.474 (28/19)
Gear Ratio: 4th 1.182 (26/22)
Gear Ratio: 5th 1.000 (24/24)
Final Reduction Ratio 3.923 (50/13)
Clutch Wet multi-disc, manual
Final Drive Chain

PERFORMANCE

Frame Tubular double cradle, box section perimeter, high-tensile steel
Front Suspension 33 mm telescopic fork
Rear Suspension Uni-Trak linkage system and single shock with piggyback reservoir, fully adjustable preload and 22-way rebound damping
Front Wheel Travel 180mm
Rear Wheel Travel 180mm
Rake 27°
Trail 96mm
Steering Angle (L/R) 41° / 41°
Front Tyre 70/100-19
Rear Tyre 90/100-16
Front Brake/s 220 mm petal disc
Front Caliper/s Dual-piston
Rear Brake 186 mm petal disc
Rear Caliper Single-piston

DETAILS

Dimensions (LxWxH) 1895 x 790 x 1075
Overall Length 1895
Overall Width 790
Overall Height 1075
Wheelbase 1285
Road Clearance 255
Seat Height 800
Curb Mass 95 kg
Fuel Capacity 5.8L

SKU 3038
Brand Kawasaki
