DEALERSHIP IS LOCATED IN SYDNEY CASTLE HILL

**STOCK LEVEL SUBJECT TO MANUFACTURER SUPPLY**

ADDITIONAL VEHICLE FEATURES:
Low 780 mm seat height
180 mm of front and rear suspension travel
Disc brakes front and rear
POWER
Maximum Power    8.3 kW {11 PS} / 8,000 rpm
Maximum Torque    12.0 Nm {1.2 kgfm} / 6,000 rpm
Engine    4-stroke Single
Displacement    144 cc
Bore x Stroke    58.0 x 54.4 mm
Compression Ratio    9.5:1
Valve System    SOHC, 2 valves
Fuel System    Carburettor: Keihin PB20
Ignition    Digital DC-CDI
Starting    Electric
Cooling    Air-cooled
Lubrication    Forced lubrication, wet sump
Transmission    5-speed, return
Primary Reduction Ratio    2.880 (72/25)
Gear Ratio: 1st    2.667 (40/15)
Gear Ratio: 2nd    1.895 (36/19)
Gear Ratio: 3rd    1.474 (28/19)
Gear Ratio: 4th    1.182 (26/22)
Gear Ratio: 5th    1.000 (24/24)
Final Reduction Ratio    3.571 (50/14)
Clutch    Wet multi-disc, manual
Final Drive    Chain
PERFORMANCE
Frame    Perimeter, box-section, high-tensile steel
Front Suspension    ø33 mm telescopic fork
Rear Suspension    Uni Trak, single shock with adjustable spring preload
Front Wheel Travel    180 mm
Rear Wheel Travel    180 mm
Rake    27.0°
Trail    85 mm
Steering Angle (L/R)    41° / 41°
Front Tyre    70/100-17 40M
Rear Tyre    90/100-14 49M
Front Brake/s    ø220 mm petal disc
Front Caliper/s    Dual-piston
Rear Brake    ø186 mm petal disc
Rear Caliper    Single-piston
DETAILS
Dimensions (LxWxH)    1,820 x 790 x 1,050 mm
Wheelbase    1,260 mm
Road Clearance    235 mm
Seat Height    780 mm
Curb Mass    93 kg
Fuel Capacity    5.8 litres
Model Code    KLX140ARFNN
