ADDITIONAL VEHICLE FEATURES:
- Low 760 mm seat height
- Front and rear disc brakes
- Steel semi-double cradle frame
Engine | 2-stroke Single |
Displacement | 64 cc |
Bore x Stroke | 44.5 x 41.6 mm |
Compression Ratio | 8.4:1 |
Induction | 4-petal piston reed valve |
Fuel System | Carburettor: Mikuni VM24SS |
Ignition | Digital-CDI |
Starting | Primary kick |
Cooling | Liquid-cooled |
Lubrication | Pre-mix (32:1) |
Transmission | 6-speed, return |
Primary Reduction Ratio | 3.500 (77/22) |
Gear Ratio: 1st | 2.846 (37/13) |
Gear Ratio: 2nd | 2.125 (34/16) |
Gear Ratio: 3rd | 1.722 (31/18) |
Gear Ratio: 4th | 1.428 (30/21) |
Gear Ratio: 5th | 1.217 (28/23) |
Gear Ratio: 6th | 1.083 (26/24) |
Final Reduction Ratio | 3.615 (47/13) |
Clutch | Wet multi-disc, manual |
Final Drive | Chain |
Frame | Semi-double cradle, high-tensile steel, with detachable left-side rear section |
Front Suspension | ø33 mm telescopic fork with adjustable rebound damping |
Rear Suspension | Bottom-link Uni Trak, gas-charged shock with adjustable rebound damping and adjustable spring preload |
Front Wheel Travel | 210 mm |
Rear Wheel Travel | 240 mm |
Rake | 27° |
Trail | 60 mm |
Steering Angle (L/R) | 40° / 40° |
Front Tyre | 60/100-14 30M |
Rear Tyre | 80/100-12 41M |
Front Brake/s | ø180 mm disc |
Front Caliper/s | Single-piston |
Rear Brake | ø180 mm disc |
Rear Caliper | Single-piston |
Dimensions (LxWxH) | 1,590 x 760 x 955 mm |
Wheelbase | 1,120 mm |
Road Clearance | 305 mm |
Seat Height | 760 mm |
Curb Mass | 60 kg |
Mass without Fuel | 57.2 kg |
Fuel Capacity | 3.8 litres |
Model Code | KX65CRFNN |
SKU | 3326 |
Brand | Kawasaki |
